DEYE SUN-30K-SG01HP3-EU-BM3

Technical product features:

Hybrid functionality:

• Supports on-grid, off-grid, and battery storage applications
• Can store energy from a diesel generator to enhance reliability

High charging/Discharging power:

• Max charging current: 100A (50A + 50A per battery input)
• Max discharging current: 100A (50A + 50A per battery input)

Battery compatibility:

• Supports high-voltage lithium-ion batteries (160V-800V)
• Dual battery inputs for increased flexibility and power expansion

Scalability and parallel operation:

• Supports up to 10 inverters in parallel, allowing higher capacity installations
• AC coupling option for easy retrofitting into existing solar systems

Advanced MPPT technology:

• Max PV input power: 48,000W
• MPPT voltage range: 150V-850V
• Max PV input current: 55A per MPPT tracker
• 3 MPPT trackers for optimized energy harvesting

AC input/output:

• Rated power: 30,000W
• Max apparent power: 33,000VA
• Grid voltage: 220/380V, 230/400V
• Grid frequency: 50Hz/60Hz

Peak power handling:

• 1.5 times the rated power for 10 seconds (off-grid mode)

Efficiency ratings:

• Max efficiency: 97.6%
• European efficiency: 97.0%
• MPPT efficiency: >99%

Comprehensive protection and safety:

• DC reverse polarity protection
• AC overvoltage, overcurrent, and short-circuit protection
• Ground fault detection and islanding protection
• Optional arc fault circuit interrupter (AFCI) for enhanced safety
• Surge Protection Level: TYPE II (DC) / TYPE II (AC)

Communication and monitoring:

• Supports GPRS, WiFi, Bluetooth, 4G, and LAN (optional)
• RS485, RS232, and CAN communication interfaces for real-time monitoring

Physical and environmental characteristics:

• Ingress protection (IP Rating): IP65 (suitable for indoor and outdoor installations)
• Operating temperature: -40°C to +60°C
• Storage temperature: 0°C to 35°C
• Humidity range: 0-100%
• Noise level: ≤65dB
• Altitude limit: ≤2000m
• Cooling system: Intelligent Air Cooling
• Cabinet size (W/D/H): 527 × 894 × 294 mm
• Weight: 80 kg

Certifications and compliance:

• IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, G99, VDE-AR-N 4105
• Safety Standards: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

Warranty:

• 5 to 10 years, depending on the installation site and warranty policy
